Tesla Model 3: Filter - Oil - Rear Drive Unit (Remove and Replace)

Tesla Model 3 2017-2026 Service Manual / Rear Drive Unit / Rear Gearbox and Halfshafts / Filter - Oil - Rear Drive Unit (Remove and Replace)

Filter - Oil - Rear Drive Unit (Remove and Replace)

SPECIAL TOOLS

Skt, Oil Filter, 63.5mm X 14 (1130484-00-A)

Kit, Drive Unit Oil Drain, Model 3 (1134264-00-A)

Procedure

Replace the oil filter according to the gearbox fluid procedure. See Gearbox Fluid - Rear Drive Unit (Drain and Refill).
